JA-D45 Scissor Lift Built In Lifting Platforms
Hydraulics 4.5-ton Double Scissors Alignment Lift
JA-D45 scissor lift has great performance and it is the perfect choice for your commercial service. This heavy-duty scissor lift has four cylinders and each dual cylinder is designed work synchronously and to assure the optimal lifting level on both platforms. The JA-D45 is made stronger, more versatile, and easier to use and can lift 4500 kg.
Product Description
JA-D45 scissor lift has great performance and it is the perfect choice for your commercial service. This heavy-duty scissor lift has four cylinders and each dual cylinder is designed work synchronously and to assure the optimal lifting level on both platforms. The JA-D45 is made stronger, more versatile, and easier to use and can lift 4500 kg.
The JA-D45 Alignment Scissor Lift is a great lift to expand your shops capacity for larger vehicles and greater workload with its rugged design and increased dependability. The hefty 4.5-ton lifting capacity provides the heavy-duty workload needed for mechanics to increase efficiency and productivity for greater long-run profits.
This is perfect alignment lift for those service departments that do alignments on a variety of vehicles that may include a Smart Car® all the way to an F-450 dual wheel truck.
Features:
1. Safety descending stop & alarm
2. Safety valve for anti-explosion of hydraulic system
3. Precision machined double sided safety teeth design
4. Height limit switch(Jack)
5. Height limit switch(Main Platform)
6. Abrasion resistant slip plates for 4 wheel alignment
Additional Information
| Power supply | 220V 1ph 50Hz / 380v 3ph 50Hz |
|---|---|
| Motor power | 2.2kw |
| Noise level | ≤70dB |
| Platform length | 4000mm |
| Machine length | 4500mm |
| Platform length (Auxiliary machines) | 1470-1610mm |
| Lifting capacity | 4500KG |
| Lifting height | 1850/450MM |
| Min. height | 330/380MM |
| Lifting time | ≤55s |
| Lowering time | ≤55s |
